Technical Data

Power: ~220 - 240V / 50 - 60Hz
Ambient/work temperature: -40°C – +40°C
Protective class: I or II
Ingress protection code: IP66
Mechanical impact protection code: IK10
Surge protection: to 10kV
Life time: L90, B10 >100 000h (G5);
L80, B10 >100 000h (HE)
CRI: 70 or 80 (G5);
70 (HE, UHE)
Controls method: 1-10V, DALI, Ampdim, Dynadimmer,
as an option - socked ZHAGA with SR driver (D4i),
- external surge arrester 10kV/5kA
Photobiological risk group: RG1
Weight [kg]: 4

Product equipped with a replaceable light source LED - options:

Symbol	Light source	Colour temperature [K]	Luminous flux [lm]	P_n [W]	I_f [mA]
48 L-13W	12-LED HE	2200 (722)	1653	13	300
48 L-13W	12-LED HE	2700 (727)	1676	13	300
48 L-13W	12-LED HE	3000 (730)	1844	13	300
48 L-13W	12-LED HE	4000 (740)	1895	13	300
48 L-17W	12-LED HE	2200 (722)	2181	17	400
48 L-17W	12-LED HE	2700 (727)	2202	17	400
48 L-17W	12-LED HE	3000 (730)	2425	17	400
48 L-17W	12-LED HE	4000 (740)	2492	17	400
48 L-21W	12-LED HE	2200 (722)	2698	21	500
48 L-21W	12-LED HE	2700 (727)	2713	21	500
48 L-21W	12-LED HE	3000 (730)	2989	21	500
48 L-21W	12-LED HE	4000 (740)	3072	21	500
48 L-24W	12-LED HE	2200 (722)	3205	24	600
48 L-24W	12-LED HE	2700 (727)	3209	24	600
48 L-24W	12-LED HE	3000 (730)	3537	24	600
48 L-24W	12-LED HE	4000 (740)	3636	24	600
48 L-28W	12-LED HE	2200 (722)	3704	28	700
48 L-28W	12-LED HE	2700 (727)	3689	28	700
48 L-28W	12-LED HE	3000 (730)	4069	28	700
48 L-28W	12-LED HE	4000 (740)	4184	28	700
48 L-32W	12-LED HE	2200 (722)	4195	32	800
48 L-32W	12-LED HE	2700 (727)	4154	32	800
48 L-32W	12-LED HE	3000 (730)	4584	32	800
48 L-32W	12-LED HE	4000 (740)	4715	32	800
Luminous flux values shall be declared for ambient temperature 25°C. The class of modules used assumes 7% tolerance of the declared luminous flux value and a ±5% tolerance of the declared colour temperature value. The weight of the unit may slightly differ for individual production batches.

Symbol	Light source	Colour temperature [K]	Luminous flux [lm]	P_n [W]	I_f [mA]
48 L-13W	12-LED G5	2700 (827)	1438	13	300
48 L-13W	12-LED G5	3000 (830)	1516	13	300
48 L-13W	12-LED G5	4000 (840)	1602	13	300
48 L-17W	12-LED G5	2700 (827)	1870	17	400
48 L-17W	12-LED G5	3000 (830)	1970	17	400
48 L-17W	12-LED G5	4000 (840)	2083	17	400
48 L-21W	12-LED G5	2700 (827)	2284	21	500
48 L-21W	12-LED G5	3000 (830)	2407	21	500
48 L-21W	12-LED G5	4000 (840)	2545	21	500
48 L-24W	12-LED G5	2700 (827)	2683	24	600
48 L-24W	12-LED G5	3000 (830)	2828	24	600
48 L-24W	12-LED G5	4000 (840)	2990	24	600
48 L-28W	12-LED G5	2700 (827)	3069	28	700
48 L-28W	12-LED G5	3000 (830)	3235	28	700
48 L-28W	12-LED G5	4000 (840)	3421	28	700
48 L-32W	24-LED G5	2700 (827)	3444	32	800
48 L-32W	24-LED G5	3000 (830)	3630	32	800
48 L-32W	24-LED G5	4000 (840)	3839	32	800
48 L-13W	12-LED UHE	3000 (830)	2034	13	300
48 L-13W	12-LED UHE	4000 (840)	2064	13	300
48 L-17W	12-LED UHE	3000 (830)	2681	17	400
48 L-17W	12-LED UHE	4000 (840)	2721	17	400
48 L-21W	12-LED UHE	3000 (830)	3316	21	500
48 L-21W	12-LED UHE	4000 (840)	3366	21	500
48 L-24W	12-LED UHE	3000 (830)	3938	24	600
48 L-24W	12-LED UHE	4000 (840)	3998	24	600
48 L-28W	12-LED UHE	3000 (830)	4550	28	700
48 L-28W	12-LED UHE	4000 (840)	4618	28	700
48 L-32W	12-LED UHE	3000 (830)	5150	32	800
48 L-32W	12-LED UHE	4000 (840)	5228	32	800
Luminous flux values shall be declared for ambient temperature 25°C. The class of modules used assumes 7% tolerance of the declared luminous flux value and a ±5% tolerance of the declared colour temperature value. The weight of the unit may slightly differ for individual production batches.
